How To Add and Use Cisco Switch Like VLANs in pfSense Routers

Updated May 13, 2018: Configuration can be done completely within the pfSense GUI

Using VLANs and Trunking to provide subnet tagged on interfaces em3 & em4
to trunked interfaces on switches.

Available Interfaces
em2 (OPT1), em3 (OPT2), em4 (OPT3)
3 subnets each on it's own router interface to its own switch on em2 (VLAN10) on em3 (VLAN20) on em4 (VLAN30)

Note: on em2 will be untagged on em3 will be tagged on em4 will be tagged on em3 will be untagged on em4 will be untagged

This was developed on pfSense
2.4.3-RELEASE (amd64)
built on Mon Mar 26 18:02:04 CDT 2018
FreeBSD 11.1-RELEASE-p7

(Click on screenshots to zoom)

Configure Interfaces via pfSense GUI

Interfaces -> OPT1
Check Enable interface
IPv4 Configuration Type: IPv4
IPv4 Address:

Click Save

Interfaces -> OPT2
Check Enable interface
IPv4 Configuration Type: IPv4
IPv4 Address:

Click Save

Interfaces -> OPT3
Check Enable interface
IPv4 Configuration Type: IPv4
IPv4 Address:

Click Save
Click Apply Changes

Create VLANs via pfSense GUI

Interfaces -> Interface Assignments -> VLANs

Click Add
Parent Interface: em3
VLAN Tag: 10
VLAN Priority: <leave as is>
Description: vlan10

Click Save

Click Add
Parent Interface: em4
VLAN Tag: 10
VLAN Priority: <leave as is>
Description: vlan10

Click Save

Created VLANs

Interfaces -> Interface Assignments
Available network ports: From drop down box choose new em3 VLAN created
(Assuming OPT5)

Click Add

Interfaces -> Interface Assignments
Available network ports: From drop down box choose new em4 VLAN created
(Assuming OPT6)

Click Add

Click on Interface associated with em3 VLAN (Assuming OPT5)

Check Enable interface
Change Description: OPT5 to em310

Click Save

Click Apply Changes

Click on Interface associated with em4 VLAN
(Assuming OPT6)

Check Enable interface
Change Description: OPT5 to em410

Click Save

Click Apply Changes

Create Bridge via pfSense GUI

Interfaces -> Interface Assignments -> Bridges

Member Interface: OPT1, em310, em410
Click Save

Note name of bridge created

Interfaces -> Interface Assignments
Available network ports: From drop down box choose new bridge created
(Assuming BRIDGE0)

Click Add

Click on Interface associated with bridge
(Assuming OPT7)

Check Enable interface
Change Description: OPT5 to BRIDGE0

Click Save

Click Apply Changes

VLAN and Bridge setup complete

Add firewall rules for BRIDGE0 via pfSense GUI

Firewall -> Rules
Apply Changes
(As needed)

That's it. Assuming your switches are set up and connected.

Switch interfaces configuration:
switch connected to em2: Access, VLAN10 untagged
switch connected to em3: Trunk, VLAN10 tagged, VLAN20 untagged
switch connected to em4: Trunk, VLAN10 tagged, VLAN30 untagged
These are 3 separate independent switches, do not connected these 3 interfaces to the same switch or any combiantion of 2 of these interfaces to the same switch.

If anything was missed or there are questions, errors, or discrepancies please email me at:
pfs (at) curtronics (dot) com
